MN032 is a powerful software license by ABRITES, allowing you to work with used or new FBS4 modules in Mercedes-Benz vehicles effortlessly.

Functionalities:

• Set FBS4 Electronic Control Modules to virgin state
• Read the personalization data from a FBS4 Control Modules and save it to a file
• Program personalization data from a previously saved FBS4 file
• Program personalization data from a previously read dump file (dflash/ EEPROM)
• VIN programming
• Read and display FBS4 status by OBD for ALL FBS4 Control Modules
• FBS4 Control Modules Activation

Supported modules:


• VGS-FDCT/VGS2-FDCT, VGS4-NAG2 (MN035 required!), VGSNAG3, 8G FDCT, GT-DCT

-    Reading FBS4 data via OBD
-    Setting to virgin state and personalization via ZN151


• VGS-FDCT/VGS2-FDCT, VGSNAG3

-    Setting to virgin state and personalization via ABPROG (or SET088)
VGS4-NAG2 (0 and 500)


• DSM (all types of models) installed in VGS4-NAG2 (7G) cars

-    Reading and writing FBS4 data via internal CAN-Bus connection
-    Setting to virgin state via internal CAN-Bus connection – No need to open the module!
-    Personalization via internal CAN-Bus connection – No need to open the module!


• For ALL Engine modules

-    Reading FBS4 data by OBD
-    Setting to virgin state by OBD
MED17, EDC17, SID310, CRD3 ECUs (CR40, CR41, CR42, CR43, CR6, CR60, CR61, MED40, MED177, MED1773, MED1775, CRR1, CRR1+, CRD3, CRD3S2)
-    Setting to virgin state via ABRITES Distribution Box Set (ZN151)  - required for
MED41, MRD1, MRG1, CRR2 up to 2021
-    Personalization by OBD (Extended personalization)


• Hybrid vehicle ECUs (INV20EM01 and derivatives)

-    Reading FBS4 data by OBD
-    Setting to virgin state via OBD – No need to open the module!
-    Personalization by OBD (Extended personalization)


• Electric vehicle ECUs (EM01, EM02)

-    Reading FBS4 data by OBD
-    Personalization by OBD (Extended personalization)


Required tools:

• AVDI – essential in order to use all ABRITES-based products and establish OBD connection
• Abrites Distribution Box Set (ZN151)
• Abrites ABPROG (ZN030)
• DSM/ISM Direct CAN BUS Connection Cable (CB034)
• Mercedes-Benz MD1/MG1 ECU connection cable for FBS4 Manager and ECU Programming Tool (CB030)
• Extended Cable Set for all TCUs which require bench connection (CB403) – for owners of the ZN051 (older iteration of the Distribution Box Set)
